逆向工程之内存物理地址

原创

高尉峰高尉峰

ShadowRoot

2026年2月14日 10:59 河北

段寄存器

在x86汇编语言中，DS是Data Segment（数据段）寄存器的缩写，DS用于指向当前数据段的基地址。在访问内存中的数据时，CPU会使用基地址和偏移地址来定位数据的位置。

其他段寄存器：

CS (Code Segment) – 代码段
SS(Stack Segment) – 堆栈段
ES(Extra Segment) – 附加段

例子：

cmp&nbsp;dword ptr ds:[var1],&nbsp;20&nbsp; ; 定义一个4字节的var1变量，初始值为20

ds：明确指定使用DS段寄存器
[var1]：表示var1变量的偏移地址
DWORD（Double Word）是汇编语言中的一个数据类型指示符。

BYTE&nbsp; &nbsp; =&nbsp;1&nbsp;字节 (8位) &nbsp; 范围:&nbsp;0-255WORD&nbsp; &nbsp; =&nbsp;2&nbsp;字节 (16位) &nbsp;范围:&nbsp;0-65535DWORD&nbsp; &nbsp;=&nbsp;4&nbsp;字节 (32位) &nbsp;范围:&nbsp;0-4294967295QWORD&nbsp; &nbsp;=&nbsp;8&nbsp;字节 (64位) &nbsp;范围:&nbsp;0-18446744073709551615

内存模型

平坦内存模型：

所有段寄存器（CS, DS, SS, ES）的基址都是0物理地址 = 0 + 变量的偏移地址

保护模式内存模型：

物理地址 = 段基址（从描述符表获取）+ 偏移地址

实模式内存模型：

物理地址 = DS基址 ×&nbsp;16&nbsp;+ 偏移地址
Example:DS寄存器基址(1000h)，偏移地址(0020h)物理地址 =&nbsp;1000h&nbsp;×&nbsp;16&nbsp;=&nbsp;10000h&nbsp;+&nbsp;0020h&nbsp;=&nbsp;10020h

例子：

&nbsp; .386p&nbsp; .model flat,stdcall&nbsp; option casemap:none.data&nbsp; var1 DWORD&nbsp;20&nbsp; &nbsp; ; 假设var1的偏移地址0x00403000&nbsp; var2 DWORD&nbsp;10&nbsp; &nbsp; ; 假设var2的偏移地址0x00403004.code&nbsp; ; 平坦内存模型&nbsp; mov eax, ds:[var1] &nbsp;; 物理地址=0&nbsp;+&nbsp;00403000h&nbsp;=&nbsp;00403000h&nbsp; mov ebx, [var2] &nbsp; &nbsp; ; 物理地址=0&nbsp;+&nbsp;00403004h&nbsp;=&nbsp;00403004h&nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; ; (ds:可以省略)

C语言和汇编语言的关系

#include&nbsp;<stdio.h>#include&nbsp;<windows.h>
int&nbsp;main(int&nbsp;argc,char&nbsp;* argv[]){&nbsp;&nbsp;int&nbsp;var1 =&nbsp;20;&nbsp;&nbsp;int&nbsp;var2 =&nbsp;10;&nbsp;&nbsp;int&nbsp;var3 =&nbsp;50;
&nbsp;&nbsp;if&nbsp;(var1 >=&nbsp;20&nbsp;and&nbsp;var2 <=&nbsp;100&nbsp;and&nbsp;var3 ==&nbsp;50)&nbsp; {&nbsp; &nbsp;&nbsp;printf("xor eax,eax");&nbsp; }&nbsp;&nbsp;return&nbsp;0;}

ASM:

&nbsp;&nbsp;.386p&nbsp; .model flat,stdcall&nbsp; option casemap:noneinclude&nbsp;windows.incinclude&nbsp;kernel32.incincludelib kernel32.lib.data&nbsp; var1 DWORD&nbsp;20&nbsp; var2 DWORD&nbsp;10&nbsp; var3 DWORD&nbsp;50&nbsp; flag DWORD ?.code&nbsp; main PROC&nbsp; ;&nbsp;if(var1 >=&nbsp;20&nbsp;and&nbsp;var2 <=&nbsp;100&nbsp;and&nbsp;var3 ==&nbsp;50)&nbsp; &nbsp; cmp dword ptr ds:[var1],20&nbsp; &nbsp; &nbsp;; 判断是否大于20&nbsp; &nbsp; jl L1 &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;; 不大于则跳转&nbsp; &nbsp; cmp dword ptr ds:[var2],100&nbsp; &nbsp; ; 判断是否小于100&nbsp; &nbsp; jg L1 &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;; 不小于则跳转&nbsp; &nbsp; cmp dword ptr ds:[var3],50&nbsp; &nbsp; &nbsp;; 判断是否等于50&nbsp; &nbsp; jne L1 &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; ; 不等于则跳转&nbsp; &nbsp; mov dword ptr ds:[flag],1&nbsp; &nbsp; &nbsp; ; 说明等式成立 flag=1&nbsp; &nbsp; jmp L2&nbsp; L1: mov dword ptr ds:[flag],0&nbsp; L2: cmp dword ptr ds:[flag],0&nbsp; &nbsp; je lop_end &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; ; 为0则跳转,不为0则继续执行&nbsp; &nbsp;&nbsp;xor&nbsp;eax,eax &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;; 此处是执行if语句内部&nbsp; &nbsp;&nbsp;xor&nbsp;ebx,ebx&nbsp; &nbsp;&nbsp;xor&nbsp;ecx,ecx&nbsp; &nbsp; jmp lop_end&nbsp; lop_end:&nbsp; &nbsp; nop &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp;; 直接结束&nbsp; &nbsp; invoke ExitProcess,0&nbsp; main ENDPEND main

#include&nbsp;<stdio.h>#include&nbsp;<windows.h>
int&nbsp;main(int&nbsp;argc,char&nbsp;* argv[]){&nbsp;&nbsp;int&nbsp;var1 =&nbsp;20;&nbsp;&nbsp;int&nbsp;var2 =&nbsp;10;&nbsp;&nbsp;int&nbsp;var3 =&nbsp;50;
&nbsp;&nbsp;if&nbsp;(var1 > var2 || var2 <= var3)&nbsp; {&nbsp; &nbsp;&nbsp;printf("xor eax,eax");&nbsp; }&nbsp;&nbsp;else&nbsp;if(var3 ==&nbsp;50&nbsp;|| var2 >&nbsp;10)&nbsp; {&nbsp; &nbsp;&nbsp;printf("xor ebx,ebx");&nbsp; }&nbsp;&nbsp;return&nbsp;0;}

ASM:

&nbsp;&nbsp;.386p&nbsp; .model flat,stdcall&nbsp; option casemap:noneinclude windows.incinclude kernel32.incincludelib kernel32.lib.data&nbsp; var1 DWORD&nbsp;20&nbsp; var2 DWORD&nbsp;10&nbsp; var3 DWORD&nbsp;50.code&nbsp; main PROC&nbsp; ;&nbsp;if&nbsp;(var1 > var2 || var2 <= var3)&nbsp; &nbsp; mov eax,dword ptr ds:[var1]&nbsp; &nbsp; cmp eax,dword ptr ds:[var2] &nbsp; &nbsp; ; var1 > var2&nbsp; &nbsp; jg L1&nbsp; &nbsp; mov eax,dword ptr ds:[var2]&nbsp; &nbsp; cmp eax,dword ptr ds:[var3] &nbsp; &nbsp; ; var2 <= var3&nbsp; &nbsp; jg L2 &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; ; 条件是 var2 > var3 则跳转&nbsp; L1:&nbsp; &nbsp;&nbsp;xor&nbsp;eax,eax &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; ;&nbsp;printf("xor eax,eax")&nbsp; &nbsp; jmp lop_end&nbsp; L2:&nbsp; ;&nbsp;else&nbsp;if(var3 ==&nbsp;50&nbsp;|| var2 >&nbsp;10)&nbsp; &nbsp; cmp dword ptr ds:[var3],50&nbsp; &nbsp; je L3&nbsp; &nbsp; cmp dword ptr ds:[var2],10&nbsp; &nbsp; &nbsp; ; var2 >&nbsp;10&nbsp; &nbsp; jle lop_end&nbsp; L3:&nbsp; &nbsp;&nbsp;xor&nbsp;ebx,ebx &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; ;&nbsp;printf("xor ebx,ebx")&nbsp; &nbsp; jmp lop_end
&nbsp; lop_end:&nbsp; &nbsp; nop&nbsp; &nbsp;&nbsp;int&nbsp;3&nbsp; &nbsp; invoke ExitProcess,0&nbsp; main ENDPEND main
